Cadenza Bronze

Calculate Shipping

Customer collect from ESK QLD - $0.00 (ETA: 1 days)
After placing your order you can phone to make an appointment to collect from our premises in ESK QLD.

The Cadenza Bronze model is using a Replicant 100 stylus and a conical aluminium cantilever. The coil wire is the famous Ortofon Aucurum wire, which is a gold plated 6NX copper wire. Field Stabilizing Element FSE, is used for optimal linearity especially during complex crescendo passages.

Cadenza Bronze is a true high-end reference cartridge, conveying music with supreme precision, impact and dynamics. Its stereo imaging capabilities illuminate the farthest corners of the soundstage in all three dimensions.

Technical data
Output voltage at 1000 Hz, 5cm/sec.	400 µV
Channel balance at 1 kHz	< 1 dB
Channel separation at 1 kHz	> 24 dB
Channel separation at 15 kHz	> 20 dB
Frequency range at - 3dB	20 - 55 kHz
Frequency response 20 Hz - 20 kHz	+1,5
Tracking ability at 315Hz at recommended tracking force *)	80 µm
Compliance, dynamic, lateral	12 µm/mN
Stylus type	Nude Ortofon replicant,, conical aluminium
Stylus tip radius	r/R 5/100 µm
Tracking force range	2,2-2,7 g (22-27 mN)
Tracking force, recommended	2,5 g (25 mN)
Tracking angle	23°
Internal impedance, DC resistance	5 Ohm
Recommended load impedance	50-200 Ohm
Cartridge body material	Stainless steel / Aluminium
Cartridge colour	Bronze/Black
Cartridge weight	10,7 gram

*) Typical value

(OCBZ)

SKU	OCBZ
Barcode #	5705796230130
Brand	ORTOFON
Shipping Weight	0.1200kg
Shipping Width	0.090m
Shipping Height	0.120m
Shipping Length	0.090m
Shipping Cubic	0.000972000m3
