AT33SA Moving Coil Cartridge

Calculate Shipping

Customer collect from ESK QLD - $0.00 (ETA: 1 days)
After placing your order you can phone to make an appointment to collect from our premises in ESK QLD.

The latest update to the venerable AT33 Series – the first extensive overhaul in years – brings new warmth and fullness to your favorite music. Incorporating technological and material improvements, including our first use of die-cast zinc at the base of the cartridge to ward off unwanted resonance and improve expressiveness in the mid to low frequencies, the AT33x Series cartridges let you hear the finest details across the audio spectrum.

The AT33xEN is an excellent all-around cartridge choice, delivering warm, full-bodied audio reproduction. It features a 0.3 x 0.7 mil elliptical nude stylus attached to a hard duralumin tapered pipe cantilever to provide excellent tracking of the record groove with enhanced high-frequency control. Our newly developed suspension mechanism uses piano wire for even better tracking accuracy, lowering the dynamic compliance slightly for more substantial audio, particularly in the mid-low range.

Features

AT33x Series dual moving coil stereo cartridge with 0.3 x 0.7 mil elliptical nude stylus
Full, warm sound is suitable for a wide variety of recordings
Dual moving coil design, featuring independent left and right coils, provides outstanding channel separation
PCOCC (Pure Copper by Ohno Continuous Casting) coils provide pure, smooth signal transmission
Neodymium magnet and permendur yoke maximize energy efficiency for high-resolution, responsive playback
Composite cartridge body (die-cast zinc, aluminum, and high-rigidity polymer) reduces resonance throughout the body for balanced, natural sound reproduction
Highly rigid and dense die-cast zinc material is used at the base of the cartridge to suppress unwanted vibrations and improve the expressiveness of the mid-to-low frequency range
Threaded mounting holes make it easier to mount the cartridge to a headshell, especially one integrated into a tonearm

0.3 x 0.7 mil elliptical nude stylus tracks the record groove with accuracy for outstanding audio reproduction
High-hardness duralumin tapered pipe cantilever enhances high-frequency control
Newly developed suspension mechanism and rubber damper design (with lower dynamic compliance than other A-T cartridges) enable the cartridge to be used with a variety of tonearms
Thick gold plating on the terminal pins reduces contact resistance and enhances sound quality
Crafted and hand-finished by artisans in Japan

Please Note: AT33xEN’s stylus assembly is not field-replaceable, but Audio-Technica offers a fee-based Moving Coil Exchange Program to properly service your moving coil cartridge.

Specifications

Frequency Response	20 to 40,000 Hz
Channel Separation	27 dB (1 kHz)
Vertical Tracking Angle	19°
Tracking Force	1.8 to 2.2 g (2.0 g standard)
Recommended Load Impedance	≥ 100 ohms (when head amplifier connected)

Coil Impedance	12 ohms (1 kHz)
DC Resistance	12 ohms
Coil Inductance	26 μH (1 kHz)
Output Voltage	0.4 mV (1 kHz, 5 cm/sec.)
Output Balance	1.0 dB (1 kHz)
Stylus Shape	Nude Elliptical
Cantilever	Duralumin tapered pipe
Static Compliance	21 × 10-6 cm/dyne
Dynamic Compliance	6 × 10-6 cm/dyne (100 Hz)
Dimensions	16.1 mm (0.63”) × 16.6 mm (0.65”) × 26.1 mm (1.0”) (H × W × D)

Accessories Included	Non-magnetic screwdriver; Brush; Washer* × 2; Cartridge installation screws* (M2.6) (8.0 mm (0.31”) × 2, 10.0 mm (0.39”) × 2, 13.0 mm (0.51”) × 2); Protector
Threaded Hole	M2.6 × 2
Stylus Curvature Radius	0.3 × 0.7 mil
Type	MC
Weight	10.1 g (0.36 oz)
Notes	* Washers × 2 and screws (8.0 mm (0.31”)) × 2 are used to secure the cartridge in the box at the time of purchase. Be sure to keep and not lose these after removing the cartridge from the box. For product improvement, the product is subject to modification without notice.

(AT33xEN)

SKU	AT33xEN
Brand	AUDIO TECHNICA
Shipping Weight	0.2000kg
Shipping Width	0.016m
Shipping Height	0.026m
Shipping Length	0.016m
Shipping Cubic	0.000007000m3
