AT33SA Moving Coil Cartridge

Calculate Shipping

Customer collect from ESK QLD - $0.00 (ETA: 1 days)
After placing your order you can phone to make an appointment to collect from our premises in ESK QLD.

The latest update to the venerable AT33 Series – the first extensive overhaul in years – brings new warmth and fullness to your favorite music. Incorporating technological and material improvements, including our first use of die-cast zinc at the base of the cartridge to ward off unwanted resonance and improve expressiveness in the mid to low frequencies, the AT33x Series cartridges let you hear the finest details across the audio spectrum.

The AT33xMONO/I features a “True Mono” dual moving coil design that is unaffected by any vertical noise components picked up from the record groove, instead generating electrical signal only from horizontal movement. This results in exceptionally clear monaural sound with a more substantial low end and reduced surface noise. The dual mono coil design is also ideal for mono playback on a stereo system.

Features

AT33x Series dual moving coil monaural cartridge with 0.65 mil conical nude stylus
Balanced, high-resolution sound reproduction brings out all the details in a piece of music
“True Mono” dual moving coil design only generates electrical signal from horizontal movement for exceptionally clear monaural sound with a more substantial low end and reduced surface noise
PCOCC (Pure Copper by Ohno Continuous Casting) coils provide pure, smooth signal transmission
Neodymium magnet and permendur yoke (shaped for optimal monaural sound reproduction) maximize energy efficiency for high-resolution, responsive playback
Composite cartridge body (die-cast zinc, aluminum, and high-rigidity polymer) reduces resonance throughout the body for balanced, natural sound reproduction
Highly rigid and dense die-cast zinc material is used at the base of the cartridge to suppress unwanted vibrations and improve the expressiveness of the mid-to-low frequency range
Threaded mounting holes make it easier to mount the cartridge to a headshell, especially one integrated into a tonearm

0.65 mil conical nude stylus tracks the center of the record groove for reliable performance and excellent fidelity
High-hardness duralumin pipe cantilever
Newly developed suspension mechanism and rubber damper design (with lower dynamic compliance than other A-T cartridges) enable the cartridge to be used with a variety of tonearms
Thick gold plating on the terminal pins reduces contact resistance and enhances sound quality
Crafted and hand-finished by artisans in Japan

Please Note: AT33xMONO/I’s stylus assembly is not field-replaceable, but Audio-Technica offers a fee-based Moving Coil Exchange Program to properly service your moving coil cartridge.

Specifications

Frequency Response	20 to 30,000 Hz
Vertical Tracking Angle	20°
Tracking Force	2.0 to 2.4 g (2.2 g standard)
Recommended Load Impedance	≥ 100 ohms (when head amplifier connected)
Coil Impedance	10 ohms (1 kHz)
DC Resistance	10 ohms
Coil Inductance	27 μH (1 kHz)
Output Voltage	0.42 mV (1 kHz, 5 cm/sec., horizontal signal)
Output Balance	1.0 dB (1 kHz)

Horizontal/Vertical Output Ratio	25 dB (1 kHz)
Stylus Shape	Nude conical
Cantilever	Duralumin pipe
Static Compliance	14 × 10-6 cm/dyne
Dynamic Compliance	6 × 10-6 cm/dyne (100 Hz)
Dimensions	16.1 mm (0.63”) × 16.6 mm (0.65”) × 26.1 mm (1.0”) (H × W × D)
Accessories Included	Non-magnetic screwdriver; Brush; Washer* × 2; Cartridge installation screws* (M2.6) (8.0 mm (0.31”) × 2, 10.0 mm (0.39”) × 2, 13.0 mm (0.51”) × 2); Protector
Threaded Hole	M2.6 × 2

Stylus Curvature Radius	0.65 mil
Type	MC
Weight	10.1 g (0.36 oz)
Notes	* Washers × 2 and screws (8.0 mm (0.31”)) × 2 are used to secure the cartridge in the box at the time of purchase. Be sure to keep and not lose these after removing the cartridge from the box. For product improvement, the product is subject to modification without notice.

(AT33xMONO1)

SKU	AT33xMONO1
Brand	AUDIO TECHNICA
Shipping Weight	0.2000kg
Shipping Width	0.016m
Shipping Height	0.026m
Shipping Length	0.016m
Shipping Cubic	0.000007000m3
